Blister Packaging Machine HC Lab Pack model

Product Description

Blister Packaging Machine For HC Lab Pack is ideal machine for the pharmaceutical industry for the packing of Oral tablets, capsules, hard and soft gelatin.

• HC LAB PACK model is suitable for R&D purpose.
• Pharma companies uses this model in F&D.
• Servo Based machine.
• Easy to operate for R&D officer/scientist.
• Easy PLC controls through HMI touch screen.
• Foil saving and energy saving.

• Base Foil Width : 150 MM, 150 MM
• Base Foil Thickness: 0.25 MM,  0.25 - 0.40 MM
• Base Foil Material:  Aluminum,  PVC / PVDC / ACLAR / OPAQUE / TRIPLEX
• Base Foil Reel Diameter:  440 MM (Max)
• Sealing Foil Width:  150 MM
• Sealing Foil Thickness:  0.025 MM 0.025 MM
• Sealing Foil Material : Aluminum,  Aluminum / CR Foil / Laminated Paper
• Sealing Foil Reel Diameter : 210 MM (Max)
• Max. Packet Forming Area:  140 X 95 MM
• Max. Forming Depth:  10 MM,  16 MM
• Machine Speed : Upto 10 - 15 Strokes / Min.
• Approximate Weight of Machine:  650 KG
• Machine (Length X Width X Height) : 1500 X 450 X 1350 MM
• Electrical Input:  1 Phase, 3 KW, 50 Hz, 4 Wire, 2.5 Sq. MM
• Chilled Water Requirement : 50 Liters of chilled Water / Hour at 16° C Temperature
• Additional Safety:  Air Dryer, Voltage Stabilizer
• Compressed Air Requirement:  Dry Air with 5 Bar Pressure (20 CFM)
