ALU Blister Packing Machine single track

Product Description

Backed by a team of diligent experts, we have been able to manufacture and supply Single Track ALU Blister Packing Machine. In order to manufacture this machine, our professionals use quality tested raw materials and latest technology as per the set industrial norms. We offer this Single Track ALU Blister Packing Machine in varied specifications at industry-leading prices to the clients.

HC TRIUMPH BLISTER PACKING MACHINE.

• This machine is also known as Double Track Blister Machine.
• High Production output upto 600K tablets/shift.
• Machine is cam-shaft based mechanical type.
• less Air consumption and high performance.
• Servo Based machine.
• PLC based machine with 7inch color touch screen.
• Easy operation with pre-saved Recipe.
• less wastage of foil.
• Foil and energy Saving.
• PRC or I-mark facility available.
• Perforation attachment available.

• Base Foil Width: 150 MM,  150 MM
• Base Foil Thickness: 0.25 MM,  0.25 - 0.40 MM
• Base Foil Material: Aluminum , PVC / PVDC / ACLAR / OPAQUE / TRIPLEX
• Base Foil Reel Diameter: 440 MM (Max)
• Sealing Foil Width: 146 MM
• Sealing Foil Thickness: 0.025 MM,  0.025 MM
• Sealing Foil Material: Aluminum, Aluminum / CR Foil / Laminated Paper
• Sealing Foil Reel Diameter: 210 MM (Max)
• Max. Packet Forming Area: 140 X 95 MM
• Max. Forming Depth: 10 MM 16 MM
• Machine Speed Upto: 35 Strokes/ Min. 30 Strokes / Min.
• Approximate Weight of Machine: 1000 KG
• Machine (Length X Width X Height): 2600 X 1015 X 1860 MM
• Electrical Input: 1 Phase, 1.5 KW, 50 Hz, 4 Wire, 2.5 Sq. MM
• Chilled Water Requirement: 100 Liters of chilled Water / Hour at 16° C Temperature
• Additional Safety: Air Dryer, Voltage Stabilizer
• Compressed Air Requirement: Dry Air with 8 Bar continuous Pressure (10HP Compressor - 32 CFM)
